| Quantity | Unit Price | |
|---|---|---|
| 1 - 1 sets | $195128.70 | |
| 2 - 4 sets | $195086.23 | |
| 5 - 9 sets | $195043.76 | |
| 10+ sets | $195000.00 | Best Price |
| machine type | Hydraulic |
| style | Horizontal |
| distance between tie bars | 1160x1060mm |
| plastic processed | PP, PC, ABS, PET, PVC, PE, Nylon |
| key selling points | Vertical compression structure |
| core components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw |
| warranty | 3 Years |
| machinery test report | Provided |
| video outgoing-inspection | Provided |
| injection weight (g) | 5166 g |
| injection rate (g/s) | 1080 g/s |
| weight (kg) | 42000 kg |
| place of origin | Zhejiang, China |
| power (kw) | 82 kW |
| mold height(mm) | 480 - 1160 mm |
| ejector stroke(mm) | 300 mm |
| ejector force(kn) | 229 kN |
| theoretical shot volume(cm³) | 5677 cm³ |
| screw speed (rpm) | 0 - 114 rpm |
| screw diameter (mm) | 120 mm |
| Screw L/D Ratio | 19.4 |
| open stroke(mm) | 1100 mm |
| model number | SK1000D |
| brand name | SUNBUN |
| COLOR | Green+black, OEM |
| Main material | Nodular cast iron |
| Structure | Mechanical vertical compression |
| Motor | Servo motor |
| Packaging and delivery | |
| Packaging Details | STANDARD SEAWAY PACKING WITH FILM |
| Port of dispatch | Ningbo Port |
| Selling Units | Single item |
| Packaging examples | |
| Supply capacity | |
| Supply Ability | 20 sets per Month |
