| Quantity | Unit Price | |
|---|---|---|
| 2 - 3 sets | $21840.00 | |
| 4 - 9 sets | $21625.50 | -1% |
| 10 - 19 sets | $21411.00 | -2% |
| 20+ sets | $21190.00 | -3% Best Price |
| Machine type | Hydraulic |
| Style | Horizontal |
| Distance between tie bars | 420 × 420 mm |
| Plastic processed | PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, PA, Polystyrene, PE, LDPE, HDPE/PP, ABS/PP, PE/PP |
| Key selling points | High Productivity |
| Core components | PLC, Bearing, Motor, Pump, Gear, Pressure Vessel, Engine, Gearbox, Other |
| Ejector number | 5 |
| Warranty | 1 Year |
| Machinery test report | Provided |
| Video outgoing-inspection | Provided |
| Plasticizing capacity (g/s) | 125 |
| Injection weight (g) | 227 g |
| Injection rate (g/s) | 125 g/s |
| Weight (kg) | 3300 |
| Place of origin | Zhejiang, China |
| Power (kW) | 22.3 kW |
| Mold height (mm) | 150 – 450 mm |
| Ejector stroke (mm) | 120 mm |
| Ejector force (kN) | 38 kN |
| Theoretical shot volume (cm³) | 249 cm³ |
| Screw speed (rpm) | 0 – 224 rpm |
| Screw diameter (mm) | 42 mm |
| Screw L/D Ratio | 22 |
| Open stroke (mm) | 360 mm |
| Model number | SLA138 |
| Brand name | SAILAI |
| Boundary dimension (L×W×H) | 4.4 × 1.1 × 2 m |
| Max. pump pressure | 16 MPa |
| Servo motor power | 15 kW |
| Heater power | 7.3 kW |
| Heating section | 3 + 1 |
| Oil tank capacity | 200 L |
| Dimension | 4.4 × 1.1 × 2 m |
| Packaging details | Packed with moisture-proof film, fixed in a container |
| Port of dispatch | NINGBO |
| Selling Units | Single item |
| Supply ability | 80 sets per month |
