| Quantity | Unit Price | |
|---|---|---|
| 1 - 1 pieces | $5525.00 | |
| 2 - 4 pieces | $5421.61 | -2% |
| 5 - 9 pieces | $5318.22 | -4% |
| 10+ pieces | $5211.70 | -6% Best Price |
| Caractéristique | Détails |
|---|---|
| Machine Type | CNC Router |
| Number of Axes | 3 |
| No. of Spindles | Single |
| Voltage | 380 V |
| Warranty | 1 Year |
| Key Selling Points | Competitive Price |
| Core Components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| CNC or Not | CNC |
| Place of Origin | China |
| Weight (kg) | 2500 |
| Range of Spindle Speed (r.p.m) | 6000 - 18000 rpm |
| Positioning Accuracy (mm) | 0.01 |
| Travel (X axis) (mm) | 1300 |
| Travel (Y axis) (mm) | 2500 |
| Repeatability (X/Y/Z) (mm) | 0.03 |
| Spindle Motor Power (kW) | 9 |
| Dimension (L*W*H) | 4000 * 2000 * 1800 mm |
| Product Name | ATC CNC Router Machine |
| Application | Kitchen Cabinet Doors, Furniture Making |
| After-sales Service Provided | Service Machinery Overseas |
| Control System | LNC / Syntec control system |
| Working Area | 1300 x 2500 mm / 1300 x 2800 mm / Customized |
| Spindle Power | 9.0 kW ATC Air Cooling |
| Inverter | Fuling Inverter |
| Transmission | Taiwan TBI Ball Screw |
| Software | Ucancam / ArtCam / TYPE3 |
| Working Voltage | AC220V / AC380 / 50HZ / 60HZ |
| Packaging and Delivery | Selling Units: Single item |
| Single Package Size | 12 X 20 X 15 cm |
| Single Gross Weight | 2500.000 kg |
