| Quantity | Unit Price | |
|---|---|---|
| 4 - 7 pieces | $53300.00 | |
| 8 - 19 pieces | $52442.00 | -2% |
| 20 - 39 pieces | $51584.00 | -3% |
| 40+ pieces | $50700.00 | -5% Best Price |
| Machine Type | Hydraulic |
| Style | Horizontal |
| Distance Between Tie Bars | 680 x 680 mm |
| Plastic Processed | PET |
| Key Selling Points | High Productivity |
| Core Components | Bearing, Motor, Pump, Gear, PLC, Other, Pressure Vessel, Engine, Gearbox, Screw |
| Ejector Number | 13 |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Plasticizing Capacity (g/s) | 580 |
| Injection Weight (g) | 2369 |
| Injection Rate (g/s) | 580 |
| Weight (kg) | 12,100 |
| Place of Origin | Jiangsu, China |
| Power (kW) | 131.4 |
| Mold Height (mm) | 300 - 660 |
| Ejector Stroke (mm) | 200 |
| Ejector Force (kN) | 177 |
| Theoretical Shot Volume (cm³) | 1974.2 |
| Screw Speed (rpm) | 1 - 180 |
| Screw Diameter (mm) | 83 |
| Screw L/D Ratio | 21 |
| Open Stroke (mm) | 590 |
| Model Number | KPET |
| Brand Name | ZOEPACK-EFFICIENT |
| Injection Molding Machine Classification | Injection Molding Machine Classification |
| Injection Pressure | 160 MPa |
| Mould Thickness | 280 - 710 mm |
| Ejector Tonnage | 3280 kN |
| Machine Dimension | 7.8 x 1.7 x 2.05 m |
| Max Pump Pressure | 16 MPa |
| Oil Tank Capacity | 500 L |
| Advantages | High Speed, High Efficiency |
| Suitable Material | PET, PP |
| Service | After Sale Service |
| Packaging and Delivery | Selling Units |
| Single Package Size | 20 x 18 x 10 cm |
| Single Gross Weight | 1 kg |
| Selling Units | Single item |
