| Quantity | Unit Price | |
|---|---|---|
| 1 - 1 sets | $50518.00 | |
| 2 - 4 sets | $40603.81 | -20% |
| 5 - 9 sets | $30689.62 | -39% |
| 10+ sets | $20475.00 | -59% Best Price |
| Machine type | Electric, Hydraulic |
| Style | Horizontal |
| Product name | Plastic Injection Moulding Machine |
| Application | PET Preform, toys, clothes hanger and so on |
| Plastic processed | PP, Silicon, PC, PET, PVC, FRPP/PVC |
| Key selling points | Long Service Life, Easy To Operate, Multifunctional, Automatic |
| Core components | Bearing, Motor, Gear, PLC, Pressure Vessel, Other |
| Ejector number | Other |
| Warranty | 1 Year |
| Machinery test report | Not Available |
| Video outgoing-inspection | Provided |
| Distance between tie bars | 660 × 660 mm |
| Mould clamping force | 3380 KN |
| Open stroke | 660 mm |
| Die moving stroke | 660 mm |
| Mold height | 250 – 700 mm |
| Thickness of die | 250 – 700 mm |
| Injection weight | 1015 g |
| Injection rate | 265 g/s |
| Plasticizing capacity | 265 g/s |
| Theoretical shot volume | 1128 cm³ |
| Screw diameter | 65 mm |
| Screw speed | 0 – 160 rpm |
| Screw L/D Ratio | 23.8 |
| Ejector stroke | 170 mm |
| Ejector force | 90 kN |
| Power | 20 kW |
| Oil pump motor power | 37 kW |
| Electric heating power | 20 kW |
| Maximum pump pressure | 16 MPa |
| Weight | 11600 kg |
| Model number | PR-3380KN |
| Brand name | PRINCE |
| Place of origin | Zhejiang, China |
| After-sales Service Provided | Video Technical Support, Online Support |
| Selling Units | Single item |
