| Quantity | Unit Price | |
|---|---|---|
| 1 - 1 pieces | $143000.00 | |
| 2 - 4 pieces | $134420.00 | -6% |
| 5 - 9 pieces | $125840.00 | -12% |
| 10+ pieces | $117000.00 | -18% Best Price |
| Plastic processed | PP, HDPE, PC, ABS, PVC, PET, PE, ABS/PP, PE/PP, HDPE/PP |
| Clamping Force (kN) | 980 |
| Automation | Automatic |
| Voltage | Customized |
| Key selling points | Energy Saving |
| Warranty | 1 Year |
| No. of Screw Heating Zone | 5 |
| PLC Brand | Mitsubishi |
| Core components | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump |
| Machinery test report | Provided |
| Video outgoing-inspection | Provided |
| Output | 260 kg/h |
| Output of HDPE | 320–380 kg/h |
| Place of origin | Jiangsu, China |
| Power | 139 kW |
| Weight | 23 t |
| Brand name | LIANHUA TECHNOLOGY |
| Model Number | LHB120 |
| Dimension (L×W×H) | 6.8 × 3.6 × 5.3 m |
| Screw L/D Ratio | 28 |
| Screw diameter | 120 mm |
| Screw heating power | 32 kW |
| Extruder motor power | 75 kW |
| Mold platen size (Width) | 1200 mm |
| Mold platen size (Height) | 1300 mm |
| Air pressure | 1 MPa |
| Air consumption | 1.6 m³/min |
| Die head heating power | 39 kW |
| Hydraulic valves | Yuken |
| Parison controller system | Japan MOOG 100 Points Digipack III |
| Control | Japan PLC + Touch Screen |
| Hydraulic servo motor | Yunsheng |
| Production max volume | 250 Liter |
| After-sales Service Provided | Online support |
| After Warranty Service | Field maintenance for all life |
| Certification | CE, ISO |
| Selling Units | Single item |
| Single package size | 30 × 30 × 50 cm |
| Single gross weight | 2.000 kg |
