| Quantity | Unit Price | |
|---|---|---|
| 1 - 1 sets | $24178.70 | |
| 2 - 4 sets | $24136.23 | |
| 5 - 9 sets | $24093.76 | |
| 10+ sets | $24050.00 | -1% Best Price |
| Dimension (L*W*H) | 3500*1000*1800 mm |
| Plastic Type | PET, PVC, PS |
| Processing Type | Thermoforming |
| Production Speed | 10–35 cycles/min |
| Voltage | 380 V, 50 Hz |
| Product Type | Box, Tray, Container, Plate |
| Warranty | 1 Year |
| Key Selling Points | Automatic |
| Core Components | PLC, Motor |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Forming Width | 290 mm |
| Forming Length | 470 mm |
| Place of Origin | Zhejiang, China |
| Weight | 2.4 t |
| Max. Forming Height | 47 mm |
| Air Pressure | 0.8 MPa |
| Sheet Thickness | 0.15 – 0.6 mm |
| Heating Power | 8 kW |
| Air Consumption | 0.3 L/min |
| Water Consumption | 1 L/min |
| Brand Name | NOBLEGEYUN |
| Power | 11.5 kW |
| Material (Details) | PVC / PET / PS |
| Punch Speed | 10–35 times/min |
| Stroke | 60–300 mm |
| Forming Area | 470*290*47 mm |
| Compressed Air | 0.6–0.8 MPa |
| Mold Cooling | 60 L/H tap/recycle water |
| Controller | PLC + Touch Screen |
| Driven Type | Servo Motor Traction |
| Selling Units | Single Item |
