| Quantity | Unit Price | |
|---|---|---|
| 1 - 1 sets | $29900.00 | |
| 2 - 4 sets | $29685.50 | -1% |
| 5 - 9 sets | $29471.00 | -1% |
| 10+ sets | $29250.00 | -2% Best Price |
| Machine Type | Hydraulic |
| Style | Horizontal |
| Distance Between Tie Bars | 555 x 555 mm |
| Plastic Processed | PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, HDPE, PA, PE, LDPE, HDPE/PP, ABS/PP, PE/PP |
| Key Selling Points | Multifunctional |
| Core Components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw |
| Ejector Number | 5 |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Plasticizing Capacity | 32.5 g/s |
| Injection Weight | 720 g |
| Injection Rate | 210 g/s |
| Weight (kg) | 8000 |
| Place of Origin | Jiangsu, China |
| Power | 22 kW |
| Mold Height | 200 – 570 mm |
| Ejector Stroke | 135 mm |
| Ejector Force | 53.1 kN |
| Theoretical Shot Volume | 791 cm³ |
| Screw Speed | 0 – 150 rpm |
| Screw Diameter | 60 mm |
| Screw L/D Ratio | 21 |
| Open Stroke | 530 mm |
| Model Number | SZ-2400A |
| Brand Name | Shenzhou |
| Product Name | Plastic Injection Molding Machine |
| Keyword | Injection Molding Machine |
| Function | Multifunctional Plastic Products Making |
| Motor | Servo Energy Saving |
| Color | Customer's Request |
| Brand | SHENZHOU |
| Advantages | Energy Efficient |
| Operation Language | Multilingual (Optional) |
| Accessories | Free |
| Plastic Type | Thermoplastic |
| Selling Units | Single Item |
| Single Package Size | XX cm |
